• If required, recover the
expansion ribbon cable.
• If the iPBX has two cabinets, disconnect the expansion ribbon
cable linking the CPU card to the expansion cable connector.
• Recover the i-button
module.
• Recover, on the UCV card, the i-button module containing the
system's identifier.
• Remove the cover from
the new cabinet.
• Unscrew the two securing screws of the upper cover, at the back
of the cabinet.
• Remove the upper cover by sliding it backwards.
• Install the i-Button
module.
• Install the i-button module from the old UCV card on the new
card.
• Check the configuration of
the UCV card.
• As the UCV card can include daughter cards, check that it is
fitted identically to the previous one, unless its configuration has
been modified due to a change in its capacity (in which case, see
Sections 4.3 to 4.5 or the product “Data sheet”).
• Remove and recover the
i-button
identification number.
• Remove and recover, at the back of the cabinet, the label with
the i-Button's identifier number (the i-Button's identifier label
only, not the product identification label).
• Stick the i-Button's identification label on the back of the new
cabinet.
• If required, connect the
expansion ribbon cable.
• If the iPBX has two cabinets, connect the expansion ribbon cable
(recovered from the old cabinet) linking the CPU card to the
expansion cable connector.
• Install the expansion
cards in the new cabinet.
• Slide the cards along the guides until they click into place and lock
the cards in place using the 1/4 turn locks (see Section 4.1).
• Install the cables exactly
like in the old cabinet.
• On the front panel of the expansion cards
• On the front panel of the UCV card
• at the back of the cabinet. Do not forget to wire the protective
ground.
Attention : Do not connect the mains cable. The cabinet
must be closed.
• Close the new cabinet. • In the empty slots,
- screw in the metal blanking plates on the front panel of the
empty slots,
- fit the plastic covers and plugs on the blanking plates.
• Secure the cover,
- Fit the cover slightly to the rear of the cabinet and push it
forward.
- Tighten the two securing screws at the back of the cabinet.
• Fit the new cabinet.
Table 20:
OPERATION DETAILS OF THE OPERATION / COMMENTS
