Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Maintenance 01/2011 Page 447
E-1
• Install the expansion
cards.
Install the expansion cards from the old cabinet in the new cabinet.
• Slide the card along the card guides until it clicks into place.
• Lock the card in place using the 1/4 turn locks (see Figure 4.1 ).
• Install the cables exactly
like in the old cabinet.
• On the front panel of the expansion cards,
• connect the expansion cabinet to the main cabinet using the
connection cable(s) (see Sections§ 4.5.4.1 and 4.5.4.2).
• Do not forget to wire the protective ground.
• Fit the new cabinet.
• Connect the mains cable. • Connect one end of the mains cable to the power supply
module(s) of the expansion cabinet and the other end to a
grounded mains power point.
Attention : The iPBX must be powered off when installing
the mains cable.
Never connect network lines while the mains
power cable is unplugged.
• Power on the iPBX. • Before powering on the cabinet, check that the following tasks
have been performed:
- all line connections are installed,
- all equipment has been connected to a grounded power point.
• Power on the iPBX:
- power on the expansion cabinet then the main cabinet.
- “I/O” switch on the power supply module(s) set to “I”.
• Check the status of the indicators (see Sections 4.3 to 4.7).
Table 22:
OPERATION DETAILS OF THE OPERATION / COMMENTS
