AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 448 01/2011 Maintenance
SHEET E-16REPLACING AN EXPANSION CABINET (IPBX AXL, AXS, AXS12)
AVAILABILITY
• No mission capable
• 1 operator on site
DURATION
• 20 minutes
• 1 Facom AZXR 15*75 Torx screwdriver for M4 screw (cover).
INGRÉDIENT(S)/CONSOMMABLE(S)
•N/A
Table 23:
OPERATION DETAILS OF THE OPERATION / COMMENTS
• Back up the customer
configuration.
• Precautionary operation to be carried out if there is no existing
copy (which is the case when previous installation operations
have been carried out and the procedures followed).
• Refer to [1]
• In the case of remote operation, contact the remote operator
before starting any operation.
• Power off the iPBX. • Refer to Section 6.4, Stopping the system (AXD, AXL, AXS,
AXS12 and AXS6)Error! No bookmark name given.
• First power off the main cabinet then the expansion cabinet.
• Disconnect the cables. • Disconnect the mains cable.
• Disconnect the cables connected at the back of the expansion
cabinet.
• Disconnect the cables from the cabinet subassemblies and mark
the cables for refitting.
• Remove the old cabinet.
• Recover the expansion
cards from the old
cabinet.
• Use the 1/4 turn locks to remove the card from its slot
(see Figure 4.1 ).
• Check that the new
expansion cabinet is
powered off.
• “I/O” switch to position “O”.
• Remove the cover from
the new cabinet (AXS/
AXS12/AXS6).
This operation concerns only the AXS/AXS12/AXS6 iPBX.
• Unscrew the two securing screws of the upper cover, at the back
of the cabinet.
• Remove the upper cover by sliding it backwards.
