Program features 175
Parameter Setting Additional information
1002 EXT2 COMMANDS SEQ PROG Start, stop, direction commands for EXT2
1102 EXT1/EXT2 SEL EXT2 EXT2 activation
1106 REF2 SELECT AI1+SEQ
PROG
Sequence programming output as REF2
1201 CONST SPEED SEL NOT SEL Deactivation of constant speeds
1401 RELAY OUTPUT 1 SEQ PROG Relay output RO 1 control as defined by
parameter 8423/…/8493
1601 RUN ENABLE NOT SEL Deactivation of Run enable
1805 DO SIGNAL SEQ PROG Digital output DO control as defined by
parameter 8423/…/8493
2102 STOP FUNCTION RAMP Ramp stop
2201 ACC/DEC 1/2 SEL SEQ PROG Ramp as defined by parameter 8422/…/8452.
2202 ACCELER TIME 1 1 s Acceleration/deceleration ramp pair 1
2203 DECELER TIME 1 0s
2205 ACCELER TIME 2 20 s Acceleration/deceleration ramp pair 2
2206 DECELER TIME 2 20 s
2207 RAMP SHAPE 2 5 s Shape of the acceleration/deceleration ramp 2
3201 SUPERV 1 PARAM 171 Sequence counter (signal 0171 SEQ CYCLE
CNTR) supervision
3202 SUPERV 1 LIM LO 30 Supervision low limit
3203 SUPERV 1 LIM HI 30 Supervision high limit
8401 SEQ PROG ENABLE EXT2 Sequence programming enabled
8402 SEQ PROG START DI1 Sequence programming activation through
digital input (DI1)
8404 SEQ PROG RESET DI1(INV) Sequence programming reset (ie, reset to
state 1, when DI1 signal is lost (1 -> 0)
8406 SEQ LOGIC VAL 1 DI4 Logic value 1
8407 SEQ LOGIC OPER 1 AND Operation between logic value 1 and 2
8408 SEQ LOGIC VAL 2 DI5 Logic value 2
8415 CYCLE CNT LOC ST5 TO NEXT Sequence counter activation, ie, sequence
count increases every time the state changes
from state 5 to state 6.
8416 CYCLE CNT RST STATE 1 Sequence counter reset during state transition
to state 1
