Program features 57
1)
Available only if I/O and Modbus module is connected and in use.
Inhibited 06.16 Drive status word 1, bit 1
Ready to start 06.16 Drive status word 1, bit 3
Tripped 06.11 Main status word, bit 3
At setpoint 06.11 Main status word, bit 8
Limiting 06.16 Drive status word 1, bit 7
Ext1 active 06.16 Drive status word 1, bit 10
Ext2 active 06.16 Drive status word 1, bit 11
Data storage
Data storage 1 real32 47.01 Data storage 1 real32
Data storage 2 real32 47.02 Data storage 2 real32
Data storage 3 real32 47.03 Data storage 3 real32
Data storage 4 real32 47.04 Data storage 4 real32
Outputs available to the adaptive program
Output Target
I/O
RO1 10.24 RO1 source
AO1 13.12 AO1 source 2)
DIO1 11.06 DIO1 output source 2)
DIO2 11.10 DIO2 output source 2)
Start control
Ext1/Ext2 selection 19.11 Ext1/Ext2 selection
Run enable 1 20.12 Run enable 1
Ext1 in1 cmd 20.03 Ext1 in1
Ext1 in2 cmd 20.04 Ext2 in2
Ext1 in3 cmd 20.05 Ext1 in3
Ext2 in1 cmd 20.08
Ext2 in1
Ext2 in2 cmd 20.09 Ext2 in2
Ext2 in3 cmd 20.10 Ext2 in3
Fault reset 31.11 Fault reset selection
Speed control
Ext1 speed reference 22.11 Ext1 speed ref1
Speed proportional gain 25.02 Speed proportional gain
Speed integration time 25.03 Speed integration time
Acceleration time 1 23.12 Acceleration time 1
Deceleration time 1 23.13 Deceleration time 1
Frequency control
Ext1 frequency reference 28.11 Ext1 frequency ref1
Torque control
Ext1 torque reference 26.11 Torque ref1 source
Ext2 torque reference 26.12 Torque ref2 source
Limit function
Minimum torque 2 30.21 Min torque 2 source
Maximum torque 2 30.22 Max torque 2 source
Events
External event 1 31.01 External event 1 source
External event 2 31.03 External event 2 source
External event 3 31.05 External event 3 source
Inputs available to the adaptive program
Input Source
