ABB DCS800 Hardware Manual

Dimensional drawings
106
3ADW000194R0611 DCS800 Hardware Manual f us
Module D4
DCS800-S01-0610
DCS80
0-S01-0740
DCS800-S01-0900
DCS80
0-S02-0680
DCS800-S02-0820
DCS800-S02-1000
600 V types
DCS800-S01-0590
DCS800-S02-0650
Weight appr. 38 kg
S = 10 mm
SS
f. M6
48.5
270
225
644
625
107
52
40
80
80
80
f. M12
45
U1
V1
W1
C1
D1
for size D4
fan terminal
Power terminal: Busbar 40x5 mm
Weight appr. 38 kg
D4_dim_b.dsf
345
298
8.7
250
577
150
9
287.5(CON-4)
240(PIN-4)
195.5
147.5
25
20
42
fan terminal
min. Top clearance
min. Bottom clearance
Earthing
M12
Direction of air flow

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
