ABB DCS800 Hardware Manual

Technical data
72
3ADW000194R0611 DCS800 Hardware Manual f us
Current ratings - IEC regenerative
* as option
Note
AC current I
AC
= 0.82*I
DC
Sizing
Note 1: The ratings apply at ambient temperature of 40 °C (104 °F). In lower temperatures the D5, D6, D7 ratings
are higher (except I
max
).
Note 2: Use the DriveSize PC tool for a more accurate dimensioning if the ambient temperature is below 40 °C
(104 °F) or the drive is loaded cyclically.
Duty cycle
Unit type I
DC I
I
DC II
I
DC III
I
DC IV
Size
internal
field curr.
4-Q converters
continu-
ous
100 %
15 min
150 %
60 s
100 %
15 min
150 %
120 s
100 %
15 min
200 %
10 s
400 V / 525 V
[A] [A] [A] [A]
DCS800-S02-0025-04/05 25 23 35 22 33 21 42
D1 6 A
DCS800-S02-0050-04/05 50 45 68 43 65 38 76
DCS800-S02-0075-04/05 75 66 99 64 96 57 114
DCS800-S02-0100-04/05 100 78 117 75 113 67 134
DCS800-S02-0140-04/05 140 110 165 105 158 99 198
DCS800-S02-0200-04/05 200 152 228 148 222 126 252
D2 15 A
DCS800-S02-0260-04/05 260 214 321 206 309 184 368
DCS800-S02-0350-04/05 350 286 429 276 414 265 530
D3 20 ADCS800-S02-0450-04/05 450 360 540 346 519 315 630
DCS800-S02-0520-04/05 520 398 597 385 578 356 712
DCS800-S02-0680-04/05 680 544 816 538 807 492 984
D4 25 ADCS800-S02-0820-04/05 820 664 996 648 972 598 1196
DCS800-S02-1000-04/05 1000 766 1149 736 1104 675 1350
DCS800-S02-1200-04/05 1200 888 1332 872 1308 764 1528
D5
25 A *
+S164
DCS800-S02-1500-04/05 1500 1200 1800 1156 1734 1104 2208
DCS800-S02-2000-04/05 2000 1479 2219 1421 2132 1361 2722
DCS800-S02-2050-05 2050 1550 2325 1480 2220 1450 2900
D6 -DCS800-S02-2500-04/05 2500 2000 3000 1930 2895 1790 3580
DCS800-S02-3000-04/05 3000 2330 3495 2250 3375 2080 4160
DCS800-S02-3300-04/05 3300 2416 3624 2300 3450 2277 4554
D7 -DCS800-S02-4000-04/05 4000 2977 4466 2855 4283 2795 5590
DCS800-S02-5200-04/05 5200 3800 5700 3669 5504 3733 7466
600 V / 690 V
DCS800-S02-0320-06 320 256 384 246 369 235 470 D3 -
DCS800-S02-0650-06 650 514 771 508 762 462 924 D4 -
DCS800-S02-0900-06/07 900 684 1026 670 1005 594 1188
D5
25 A *
+S164
DCS800-S02-1500-06/07 1500 1200 1800 1104 1656 1104 2208
DCS800-S02-2050-06/07 2050 1520 2280 1450 2175 1430 2860
D6 -DCS800-S02-2500-06/07 2500 1940 2910 1870 2805 1740 3480
DCS800-S02-3000-06/07 3000 2270 3405 2190 3285 2030 4060
DCS800-S02-3300-06/07 3300 2416 3624 2300 3450 2277 4554
D7 -DCS800-S02-4000-06/07 4000 3036 4554 2900 4350 2950 5900
DCS800-S02-4800-06/07 4800 3734 5601 3608 5412 3700 7400
800 V
DCS800-S02-1900-08 1900 1500 2250 1430 2145 1400 2800
D6 -DCS800-S02-2500-08 2500 1910 2865 1850 2775 1710 3420
DCS800-S02-3000-08 3000 2250 3375 2160 3240 2000 4000
DCS800-S02-3300-08 3300 2655 3983 2540 3810 2485 4970
D7 -DCS800-S02-4000-08 4000 3036 4554 2889 4334 2933 5866
DCS800-S02-4800-08 4800 3734 5601 3608 5412 3673 7346
990 V
DCS800-S02-2050-10 2050 1577 2366 1500 2250 1471 2942
D7 -
DCS800-S02-2600-10 2600 2000 3000 1900 2850 1922 3844
DCS800-S02-3300-10 3300 2551 3827 2428 3642 2458 4916
DCS800-S02-4000-10 4000 2975 4463 2878 4317 2918 5836
1190 V Data on request
100%
I
DCI
t
150%
100%
15 min
I
DCII
t
150%
100%
15 min
I
DCIII
t
200%
100%
15 min
I
DCIV
t

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
