ABB DCS800 Hardware Manual

Technical data
71
3ADW000194R0611 DCS800 Hardware Manual f us
Current ratings - IEC non regenerative
The current ratings for the DCS800 with 50 Hz and 60 Hz supplies are given below. The symbols are
described below the table.
Power converter module currents with corresponding load cycles.
The characteristics are based on an ambient temperature of max. 40°C and an elevation of max.
1000 m a.s.l.
* as option
Note
AC current I
AC
= 0.82*I
DC
Unit type I
DC I
I
DC II
I
DC III
I
DC IV
Size
internal
field curr.
2-Q converters
continu-
ous
100 %
15 min
150 %
60 s
100 %
15 min
150 %
120 s
100 %
15 min
200 %
10 s
400 V / 525 V
[A] [A] [A] [A]
DCS800-S01-0020-04/05 20 18 27 18 27 18 36
D1 6 A
DCS800-S01-0045-04/05 45 40 60 37 56 38 76
DCS800-S01-0065-04/05 65 54 81 52 78 55 110
DCS800-S01-0090-04/05 90 78 117 72 108 66 132
DCS800-S01-0125-04/05 125 104 156 100 150 94 188
DCS800-S01-0180-04/05 180 148 222 144 216 124 248
D2 15 A
DCS800-S01-0230-04/05 230 200 300 188 282 178 356
DCS800-S01-0315-04/05 315 264 396 250 375 230 460
D3 20 ADCS800-S01-0405-04/05 405 320 480 310 465 308 616
DCS800-S01-0470-04/05 470 359 539 347 521 321 642
DCS800-S01-0610-04/05 610 490 735 482 723 454 908
D4 25 ADCS800-S01-0740-04/05 740 596 894 578 867 538 1076
DCS800-S01-0900-04/05 900 700 1050 670 1005 620 1240
DCS800-S01-1200-04/05 1200 888 1332 872 1308 764 1528
D5
25 A *
+S164
DCS800-S01-1500-04/05 1500 1200 1800 1156 1734 1104 2208
DCS800-S01-2000-04/05 2000 1479 2219 1421 2132 1361 2722
DCS800-S01-2050-05 2050 1550 2325 1480 2220 1450 2900
D6 -DCS800-S01-2500-04/05 2500 1980 2970 1880 2820 1920 3840
DCS800-S01-3000-04/05 3000 2350 3525 2220 3330 2280 4560
DCS800-S01-3300-04/05 3300 2416 3624 2300 3450 2277 4554
D7 -DCS800-S01-4000-04/05 4000 2977 4466 2855 4283 2795 5590
DCS800-S01-5200-04/05 5200 3800 5700 3669 5504 3733 7466
600 V / 690 V
DCS800-S01-0290-06 290 240 360 225 337 205 410 D3 -
DCS800-S01-0590-06 590 470 705 472 708 434 868 D4 -
DCS800-S01-0900-06/07 900 684 1026 670 1005 594 1188
D5
25 A *
+S164
DCS800-S01-1500-06/07 1500 1200 1800 1104 1656 1104 2208
DCS800-S01-2000-06/07 2000 1479 2219 1421 2132 1361 2722
DCS800-S01-2050-06/07 2050 1520 2280 1450 2175 1430 2860
D6 -DCS800-S01-2500-06/07 2500 1940 2910 1840 2760 1880 3760
DCS800-S01-3000-06/07 3000 2530 3795 2410 3615 2430 4860
DCS800-S01-3300-06/07 3300 2416 3624 2300 3450 2277 4554
D7 -DCS800-S01-4000-06/07 4000 3036 4554 2900 4350 2950 5900
DCS800-S01-4800-06/07 4800 3734 5601 3608 5412 3700 7400
800 V
DCS800-S01-1900-08 1900 1500 2250 1430 2145 1400 2800
D6 -DCS800-S01-2500-08 2500 1920 2880 1820 2730 1860 3720
DCS800-S01-3000-08 3000 2500 3750 2400 3600 2400 4800
DCS800-S01-3300-08 3300 2655 3983 2540 3810 2485 4970
D7 -DCS800-S01-4000-08 4000 3036 4554 2889 4334 2933 5866
DCS800-S01-4800-08 4800 3734 5601 3608 5412 3673 7346
990 V
DCS800-S01-2050-10 2050 1577 2366 1500 2250 1471 2942
D7 -
DCS800-S01-2600-10 2600 2000 3000 1900 2850 1922 3844
DCS800-S01-3300-10 3300 2551 3827 2428 3642 2458 4916
DCS800-S01-4000-10 4000 2975 4463 2878 4317 2918 5836
1190 V Data on request

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
