ABB DCS800 Hardware Manual

Accessories
130
3ADW000194R0611 DCS800 Hardware Manual f us
Autotransformer T3
➀ 690 V transformer input cannot be used for the field converters SDCS-FEX-4 (isolation only 600 V max.)
Line reactor L3
for single phase for DCF503-0035 as well as FEX-425-Int
Type for Field curr. Transformer's Weight Power loss Fuse F3
secondary current
IF I
sec
[kg] P
V
[W] [A]
U
prim
= 500 V; 50/60Hz
T 3.01 ≤ 6 A ≤ 7 A 15 65 10
T 3.02 ≤ 12 A ≤ 13 A 20 100 16
T 3.03 ≤ 16 A ≤ 17 A 20 120 25
T 3.04 ≤ 30 A ≤ 33 A 36 180 50
T 3.05 ≤ 50 A ≤ 57 A 60 250 63
U
prim
= 690 V; 50/60Hz
T 3.11 ≤ 6 A ≤ 7 A ➀ 15 80 10
T 3.12 ≤ 12 A ≤ 13 A ➀ 20 125 16
T 3.13 ≤ 16 A ≤ 17 A ➀ 30 150 20
T 3.14 ≤ 30 A ≤ 33 A 60 230 50
T 3.15 ≤ 50 A ≤ 57 A 60 320 63
e
A
h
C
B
D
G
F 3 F 3
T 3
T 3
Type ABCDh e G
T 3.01 / T 3.11 210 110 112 75 240 10x18 95
T 3.02 / T 3.12
T 3.03
210 135 112 101 240 10x18 95
T 3.13 230 150 124 118 270 10x18 95
T 3.04 260 150 144 123 330 10x18 95
T 3.14
T 3.05 / T 3.15
295 175 176 141 380 12x18 95
4.5 Ø
2
max 70
max 80
37
52
1000
13 4
1
3
2
4
55
Input voltage: 500 V
Frequency: 50 / 60 Hz
Type line reactor data L3 Weight Pow
er
LI
rms
I
peak
loss
[μH] [A] [A] [kg] [W] [mm²]
ND30 2x >500 16 16 1.1 8 2

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
