ABB DCS800 Hardware Manual

Planning the electrical installation
36
3ADW000194R0611 DCS800 Hardware Manual f us
EMC filters
Filter in a grounded line (earthed TN or TT network)
The filters are suitable for grounded lines only, for example in public European 400 V
lines.
According to EN 61800-3 filters are not needed in insulated industrial networks with
own supply transformers. Furthermore they could cause safety risks in such floating
lines (IT networks).
According to EN 61800-3 filters are not needed in industrial zone (Second
Environment) for DCS800 drives above 100 A rated current. For rated currents
below 100 A the filter requirement is identical to Light Industry (First Environment).
Three-phase filters
EMC filters are necessary to fulfil the standard for emitted interference if a converter
shall be run at a public low voltage line, in Europe for example with 400 V. Such lines
have a grounded neutral conductor. ABB offers suitable three-phase filters for 400 V
and 25 A...600 A and 500 V filters for 440 V lines outside Europe. The filters can be
optimized for the real motor currents:
I
Filter
= 0.8 • I
MOT max
; the factor 0.8 respects the current ripple.
Lines with 500 V to 1000 V are not public. They are local networks inside factories,
and they do not supply sensitive electronics. Therefore converters do not need EMC
filters if they shall run with 500 V and more.
➀ Filter only available on request
Type of converter Constr.
type
Filter type f. y=4 Filter type f. y= 5
2-Q Converter IDC [A] 4-Q Converter IDC [A]
DCS800-S01-0020-0y 20A DCS800-S02-0025-0y 25A D1 NF3-440-25 NF3-500-25
DCS800-S01-0045-0y 45A DCS800-S02-0050-0y 50A D1 NF3-440-50 NF3-500-50
DCS800-S01-0065-0y 65A DCS800-S02-0075-0y 75A D1 NF3-440-64 NF3-500-64
DCS800-S01-0090-0y 90A DCS800-S02-0100-0y 100A D1 NF3-440-80 NF3-500-80
DCS800-S01-0125-0y 125A DCS800-S02-0140-0y 140A D1 NF3-440-110 NF3-500-110
DCS800-S01-0180-0y 180A DCS800-S02-0200-0y 200A D2 NF3-500-320 NF3-500-320
DCS800-S01-0230-0y 230A DCS800-S02-0260-0y 260A D2 NF3-500-320 NF3-500-320
DCS800-S01-0315-0y 315A DCS800-S02-0350-0y 350A D3 NF3-500-320 NF3-500-320
DCS800-S01-0405-0y 405A DCS800-S02-0450-0y 450A D3 NF3-500-600 NF3-500-600
DCS800-S01-0470-0y 470A DCS800-S02-0520-0y 520A D3 NF3-500-600 NF3-500-600
DCS800-S01-0610-0y 610A DCS800-S02-0680-0y 680A D4 NF3-500-600 NF3-500-600
DCS800-S01-0740-0y 740A D4 NF3-500-600 NF3-500-600
DCS800-S02-0820-0y 820A D4 NF3-690-1000 ➀ NF3-690-1000 ➀
DCS800-S01-0900-0y 900A DCS800-S02-1000-0y 1000A D4 NF3-690-1000 ➀ NF3-690-1000 ➀
DCS800-S01-0900-0y 900A DCS800-S02-0900-0y 900A D5 NF3-690-1000 ➀ NF3-690-1000 ➀
DCS800-S01-1200-0y 1200A DCS800-S02-1200-0y 1200A D5 NF3-690-1000 ➀ NF3-690-1000 ➀
DCS800-S01-1500-0y 1500A DCS800-S02-1500-0y 1500A D5 NF3-690-1600 ➀ NF3-690-1600 ➀
DCS800-S01-2000-0y 2000A DCS800-S02-2000-0y 2000A D5 NF3-690-1600 ➀ NF3-690-1600 ➀
≤ 3000A ≤ 3000A D6 NF3-690-2500 ➀ NF3-690-2500 ➀

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
