Planning the electrical installation
47
3ADW000194R0611 DCS800 Hardware Manual f us
Fan cooling
Fan assignment for DCS800
y = voltage class
Fan Data for DCS800
Converter type Model Configuration Fan type
DCS800-S0x-0045-04/05 ...
DCS800-S0x-00140-05/05
D1 1 2x CN2B2
DCS800-S0x-0180-04/05 ...
DCS800-S0x-0260-04/05
D2 1 2x CN2B2
DCS800-S0x-0315-04/05 ...
DCS800-S0x-0350-04/05
D3 1 2x CN2B2
DCS800-S0x-0405-04/05 ...
DCS800-S0x-0520-04/05
D3 2 4x CN2B2
DCS800-S0x-0610-04/05 ...
DCS800-S0x-0820-04/05
D4 3 1x W2E200 (230 V)
DCS800-S0x-0610-04/05 ...
DCS800-S0x-0820-04/05
D4
Pluscode E171
3 1x W2E200 (115 V)
DCS800-S0x-0900-04/05 ...
DCS800-S0x-1000-04/05
D4 3 1x W2E250 (230 V)
DCS800-S0x-0900-04/05 ...
DCS800-S0x-1000-04/05
D4
Pluscode E171
3 1x W2E250 (115 V)
DCS800-S0x-0900-0y ...
DCS800-S0x-2000-0y
D5 4 D2E 160
DCS800-S0x-1900-04/05/08 ...
DCS800-S0x-3000-04/05/08
D6 5 GR31M
400...500 V
DCS800-S0x-1900-06/07 ...
DCS800-S0x-3000-06/07
D6 5 GR31M
500...690 V
DCS800-S0x-3300-yy...
DCS800-S0x-5200-yy
D7 5 GR35C
400 V / 690 V
Fan CN2B2 W2E200 W2E 200 W2E 250 W2E 250
Rated voltage [V] 115; 1~ 230; 1~ 115; 1~ 115; 1~ 230; 1~
Tolerance [%] ±10 +6/-10 +6/-10 ±10 +6/-10
Frequency [Hz] 50 60 50 60 50 60 50 60 50 60
Power consumption [W] 16 13 64 80 64 80 120 165 135 185
Current consumpt. [A] 0.2 0.17 0.29 0.35 0.6 0.7 1.06 1.44 0.59 0.82
Blocking current [A] < 0.3 < 0.26 < 0.7 < 0,8 < 1.5 < 1.8 < 1.8 < 1.8 < 0.9 < 0.9
Air flow [m3/h] freely blowing 156 180 925 1030 925 1030 1835 1940 1860 1975
Air flow [m3/h]
at working point
-- - --
Max. ambient temperature [° C] < 60 < 75 < 75 60 60
Useful lifetime of grease appr.
40000 h/60°
appr.
45000 h/60°
appr. 45000h/60° appr.
40000 h
appr.
40000 h
Protection Impedance
➀
Temperature detector: internal connected
➀ Increased losses due to increased current with a blocked rotor will not result in a winding temper-
ature, higher than permissible for the insulation class being involved.
