ABB DCS800 Hardware Manual

The DCS800
16
3ADW000194R0611 DCS800 Hardware Manual f us
Type code
The type code contains information on the specifications and configuration of the
drive. The first digits from left express the basic configuration (e.g. DCS800-S01-
2005). The optional selections are given thereafter, on the name plate by plus code.
The main selections are described below. Not all selections are available for all
types.
Type code DCS800-AAX-YYYY-ZZ- plus code
Position
AX Y ZB
Position Plus code
Product series DCS800
A Type S0 = Converter module IP00
R0 = Rebuild system
E0 = Panel solution
A0 = Enclosed converter
X Bridge type 1 = Single bridge 2-Q
2 = Double bridge 4-Q
Y Rated current YYYY = Rated current (e.g. 0025 = 25 amps)
ZZ Rated voltage
(nominal rating in bold)
04 = 400 V
05 = 500 V
06 = 600 V
07 = 690 V
08 = 800 V
10 = 990 V
12 = 1200 V
B Power connection - = Standard D1...D6
L = Left side D7
R = Right side D7
Internal field exciter
configuration
+S164
+0S163
with internal field exciter, external supplied (only D5: 25 A, Rebuild kit: 25 A / 16 A)
without internal field exciter (only D1...D4)
Fan voltage
+S171
+S172
Size D4
Standard fan voltage: 230 V / 1-ph
fan voltage: 115 V / 1-ph
Size D6
Standard 400 V / 500 V / 800 V fan voltage: 400-500 V / 3-ph
Standard 600 V / 690 V fan voltage: 525-690 V / 3-ph
600 V / 690 V fan voltage: 400-500 V / 3-ph
Current measurement +S175 CMA; D6 and D7 converter
Voltage measurement +S186
+S180
+S181
+S182
+S183
+S189
120 V SDCS-SUB-4 for D1...D4 converter modules
600 V for D6 and D7 converter modules
690 V for D6 and D7 converter modules
800 V for D6 and D7 converter modules
990 V for D6 and D7 converter modules
galvanic isolation for D6 and D7 converter modules
SDCS-DSL board +S199
+0S199
SDCS-DSL board
no SDCS-DSL board
+ plug-in options
Control panel 0J404
J409
no DCS800 control panel
Door mounting Kit (3 m cable length)
Fieldbus K454
K451
K466
K458
Profibus RPBA
DeviceNet RDNA
Ethernet IP + Modbus TCP RETA
Modbus RMBA
I/O and DDCS L500
L501
L508
L509
Analogue Extension RAIO
Digital Extension RDIO
DDCS Adapter (10 Mbaud CH0) SDCS-COM-81
DDCS Adapter (5 Mbaud CH0) SDCS-COM-82

ABB DCS800 Specifications

General

Control Type	Digital
Supply Voltage	380 ... 690 V AC
Input Voltage Range	380 V to 690 V AC
Control Mode	Torque, Speed
Cooling Method	Air-cooled
Communication Protocols	Modbus, Profibus, CANopen
Communication Options	Ethernet
Protection Class	IP21, IP54
Enclosure Rating	IP00, IP21, IP54
Protection	Overcurrent, Overvoltage, Overtemperature
Ambient Temperature	0 to 40°C
Field Supply	Integrated or External
