Page #41 background imageLoading...
Page #41 background image
ValueParameter
Max. Grms = 4 m/s
2
(X & Y axis), Grms =
12.8 m/s
2
(Z axis)
Vibration
Max. 5 g = 50 m/s
2
(11 ms)Bumps
After storage, the operating conditions inside the controller must be met for at least
6 hours before switching on the controller (see Operating conditions on page 41).
The robot controller shall only be stored indoors, in an environment that is dry and
dust-free. In addition, wind, temperature fluctuations, and condensation shall be
avoided.
Operating conditions
The table shows the allowed operating conditions for the controller.
ValueParameter
+5°C (+41°F)Minimum ambient temperature
+45°C (+113°F)Maximum ambient temperature
2,000 mMaximum ambient altitude
Max. Grms = 2.86 m/s
2
(X, Y, Z axis)Vibration
Max. 5 g = 50 m/s
2
(11 ms)Bumps
Note
The humidity conditions shall apply with the environmental conditions EN
60721-3-3, climatic class 3K3. For temperatures 0-30°C, the relative humidity
must not exceed 85%. For temperatures exceeding 30°C, the absolute humidity
must not exceed 25g/m
3
.
If the environmental conditions in EN 60721-3-3, climatic class 3K3, are not
possible to meet at the installation site, desiccant bags can be placed inside the
controller to achieve corresponding conditions. The desiccant bags must be
replaced regularly to maintain approved operating conditions.
Protection classes
Protection class
IP20Controller cabinet, inner compartment for
electronics
IP54FlexPendant
Noise emission
NoteDescriptionData
< 60 dB(A) LeqThe sound pressure level one
meter away from each surface
of the controller.
Noise emission
Continues on next page
Product manual - OmniCore C30 41
3HAC060860-001 Revision: P
© Copyright 2019-2022 ABB. All rights reserved.
2 Controller description
2.2 Technical data for OmniCore C30 controller
Continued
