18 | XSE RI ES G5 | 210602 6MNAA
display application manages the continuous display of operating parameters, status, alarm, or unusual
conditions on the LCD. Displayed parameters and other indicators help operators obtain quick visual
information on the status and health of the system. Displayed values scroll in the LCD at
programmable time intervals and duration.
You can customize the basic factory default LCD configuration. For example:
 Change the default parameter display time of 5 seconds (value range: 1 to 255 seconds)
 Add/define additional applications and their parameters for additional monitoring
 Activate additional annunciators or alarm indicators and assign to desired applications
IMPORTANT NOTE: PCCU provides online help topics for the Display application. Click Help from
any of the display application screens for configuration information.
For default parameters, see the table below. For default annunciators, see section 12.1 LCD visual alarm
and status codes.
Table 1-5: Default display parameters
Standard display
Format
Description
Station information
STATION ID
XXXXXXXXXXXXXXXXX
ID of the unit
DATE/TIME
MM/DD/YY
HH:MM: SS
Current date and time, 24-hour clock
CHARGER
NNNNNNNN.N Volts
Input voltage of the charging unit
BATTERY VOLTAGE
NNNNNNNN.N Volts
Battery voltage as supplied by the external
unit
LITHIUM BACK-UP?
[Yes or No]
Lithium battery used as backup
Measurement tube identification and information
TUBE # ID
XXXXXXXXXXXXXXXXX
ID of the tube
TUBE # ORIFICE DIAMETER
N.NNN INCHES
Size of the orifice plate
TUBE # SP
NNN.N PSIA
Static pressure absolute, PSIA
TUBE # DP
NNN.N IN. H2O
Differential pressure, inches H2O
TUBE # TEMPERATURE
NN. N DEG F
Flowing temperature, °F
TUBE # FLOW RATE
NNNNNN.N SCF/HR
Current flow rate, programmable SCF, MCF
or MMCF per hour
TUBE # LAST CALC.
NNNNNNNN.N SCF
Last calculated volume
TUBE # YEST. VOL.
NNNN.N MCF
Yesterday’s volume, programmable SCF,
MCF or MMCF
TUBE # ACCUM. VOL.
NNNNNN.NN MCF
Total accumulated volume, programmable
SCF, MCF or MMCF
1.2.8 Configuration files
The configuration files contain application and parameter settings which define how the device
operates. The XSeries
G5
device contains the following configuration files:
