The following is assumed:
The XFC
G5
and XRC
G5
are designed to adapt to different site scenarios. This guide covers a standard
single-tube configuration for the XFC
G5
flow computer for a common site scenario which requires:
Mounting kit
Resistance temperature detector (RTD)
Solar panel charger and mounting kit
This guide assumes an orifice plate as the meter element. The XFC
G5
and XRC
G5
support other meter
types.
To perform installations and tests, the following tools and materials are required:
Pipe mount installation:
One (1) enclosure mounting kit (includes instructions, brackets, U-bolts and fastening
hardware)
One (1) pipe saddle with mounting hardware (size determined by technician)
One (1) 2-inch x 40-inch pipe (length may be extended if mounting a solar panel).
EFM plus bolts and washers
5-valve manifold
2 stabilizers (futbols) plus bolts and washers
Wall mount installation:
One (1) enclosure mounting kit (includes instructions, brackets, U-bolts and fastening
hardware)
Four (4) wall fasteners (length and girth determined by technician based on wall thickness and
materials)
EFM plus bolts and washers
Direct mount installation for XFC
G5
:
One (1) enclosure mounting kit (includes instructions, brackets, U-bolts and fastening
hardware)
Install input lines and manifold:
Stainless steel tubing (length determined by technician)
Four (4) sets of tube fittings, including ferrule and nut pairs
One (1) manifold (3-valve or 5-valve manifold, determined by technician)
Leak-test manifold and tubing connections:
Liquid leak detector
Pressure calibration device
Install and wire the RTD to the XFC
G5
:
RTD probe with cable and cable gland installed (probe and cable length determined by
technician)
Nylon tie wraps
Antenna installation:
Refer to: XSeries
G5
Wi-Fi Kit 2106049AIAA
Solar panel installation:
One (1) solar panel with cable
