ABB X Series User Manual

21060 26M N AA | X SER IE S
G5
| 31
IMPORTANT NOTE: Large enclosures are heavy and bulky. More than one person may be required
for installation.
The following steps detail the procedures for wall-mounting the XFC
G5
or XRC
G5
by the meter run.
Materials:
 One (1) enclosure mounting kit (includes instructions, brackets, U-bolts and fastening
hardware)
 Four (4) wall fasteners (length and girth determined by technician based on wall thickness and
materials)
Wall-mount the XFC
G5
or the XRC
G5
:
Inspect the installation location:
 Verify that the wall has sufficient strength to support the hanging weight of the unit. For
details on the enclosure weight and specifications, refer to the Data Sheets.
 Verify that there are no obstructions to prevent opening the enclosure door.
 Verify that there are no obstacles to prevent the solar panels from charging during daylight
hours (if installed.)
NOTICE – Equipment damage. Screw the mounting bolts into a wall stud or wall support of
sufficient strength to support the weight of the XFC
G5
or XRC
G5
.
Install the XFC
G5
or XRC
G5
mounting brackets on the back of the enclosure using the pipe
mount instructions supplied with the mounting kit.
Determine the appropriate mounting height for the XFC
G5
or XRC
G5
to allow some
downward slope from the XIMV and manifold to the meter run tap valves. This allows
condensate to drain back into the pipe.
Drill the upper mounting holes in the wall support.
Measure the distance between the top and bottom mounting bracket holes.
Locate and drill the lower mounting holes in the wall support.
Lift and align the enclosure on the wall so that the mounting bolt holes match the pre-
drilled holes.
Insert the mounting bolts through the upper bracket holes and screw in the bolts until
tight.
Repeat this procedure for the lower bracket.
Follow the instructions supplied with the manifold and stabilizer installation kits to mount the XFC
G5
or
XRC
G5
directly on the meter run orifice.
Materials:
 One (1) 5-valve manifold
 Two (2) stabilized manifold connectors (compatible with the manifold)
Install the input lines and manifold:
Install the manifold on the XIMV using the manufacturer's instructions.
Locate the tap valves on the meter run orifice and the corresponding high and low inputs
on the installed manifold.
Measure, cut, and bend the tubing to ease installation of the fittings into the orifice tap
valves and the manifold.
Install the nut and ferrule onto the tubing end.
