98 | XSE RI ES G5 | 210602 6MNAA
Restart the device for the public key update to take effect (Figure 9-27).
Return to PCCU (if you remained connected via MMI or USB).
Select View>Expert on the top PCCU menu. Wait for the view to change.
Select the station name at the top of the navigation tree.
Select Station Setup.
On the System Shutdown/then Reset value field select Yes from the dropdown.
Click Send. Wait for the device to restart. Note that the FileZilla STFP connection will be
closed when the device restarts.
Figure 9-27: Restart Totalflow device after public key update
With the key upload complete, a new private-public key pair is available for authentication. Test the
authentication with these new keys next.
9.7.3.4 Verify authentication with new private-public key pair
Verify that the public key update is successful by establishing a new SFTP connection from FileZilla,
using the newly created key and passphrase to authenticate.
To verify:
Restart FileZilla.
Click Open the Site Manager. The Site Manager window displays.
Configure the General tab parameters as follows:
• Host: Type the device’s IP address
• Port: Type 9696
• Protocol: Select SFTP- SSH File Transfer Protocol from the drop-down menu.
• Logon Type: Select Key file from the drop-down menu.
• User: Type the user required per account type (For the Totalflow-user account, type
“totalflow”. For the developer or tech-support accounts, type “root”.)
Click Browse to locate and select the newly created private key.
Click Connect.
At the passphrase prompt, type the passphrase for the newly created private key.
When the connection is successful, the FileZilla’s new site screen displays showing the
device file system (directories).
