21060 26M N AA | X SER IE S
G5
| 29
One (1) solar panel mounting kit (includes U-bolts, brackets, and hardware)
Mounting pipe extension and coupling if required (length determined by technician depending
on the size of the solar panel)
Nylon tie wraps
Install the battery:
One (1) battery with cable attached
The XFC
G5
and XRC
G5
and additional parts ship in a specially-designed shipping carton with a Quick
start guide, Safety and compliance notice, and packing list.
IMPORTANT NOTE: Inspect the contents for damage before discarding the shipping and packing
materials.
Unpack the XFC
G5
or XRC
G5
and inspect for damaged, missing or incorrect parts:
Inspect the shipping carton for damage.
Carefully remove items from the carton.
Keep all shipping materials to return any damaged or incorrect parts.
Compare the packing list with the materials received. Check for missing or incorrect parts.
Inspect each item for damage: XFC
G5
or XRC
G5
exterior, LCD display, optional equipment if
purchased.
If there are missing, incorrect, damaged parts or noticeable defects, call the ABB main
office number listed in Contact us.
IMPORTANT NOTE: Do not return equipment to ABB without prior written consent. Returns are
subject to the terms and conditions specified by ABB.
IMPORTANT NOTE: Select a mounting location that allows for easy access, is close to the tap
valves, and complies with all local and national codes.
Materials:
One (1) enclosure mounting kit (includes instructions, brackets, U-bolts and fastening
hardware)
One (1) pipe saddle with mounting hardware (size determined by technician)
One (1) 2-inch x 40-inch pipe (length may be extended if mounting a solar panel). See Figure
4-1: Solar panel .
Pipe-mount the XFC
G5
(XRC
G5
is similar):
Position the pipe saddle on the meter run and temporarily attach the saddle to the meter
run pipe using the associated hardware.
