Figure 5-3
:
XFC
G5
R-485 COMM1
IMPORTANT NOTE:
T
ypically
, only BUS+, BUS- and GND may be required to commun
icate with
a third-party RS-485 device. The
figure above illustra
t
es all lines associated with th
e COMM1 or
COMM2 RS-485 module.
Figure 5-4
:
XFC
G5
R-485 COMM2
Table 5-4
:
XFC
G5
RS
-485 COMM1 and COMM 2
PIN
RS
-485 COMM1
RS
-485 COMM2
1
GND
GND
2
VBA
TT
VBA
TT
3
Sw VBA
TT
Sw VBA
TT
4
BUS (+)
5
BUS (+)
6
BUS (-)
7
BUS (-)
8
RR
TS
12
BUS (+)
13
BUS (-)
14
RR
TS
45
47
