• Host: Type the device’s IP address.
• Port: Type 9696.
• Protocol: Select SFTP- SSH File Transfer Protocol from the drop-down menu.
• Logon Type: Select Key file from the drop-down menu.
• User: Type root.
Click Browse to select the current private key. If the keys are being changed for the first
time, use the default developer or tech-support private key provided by ABB. If the keys
were previously updated, then use those keys instead.
Click Connect.
Figure 9-21: FileZilla Site Manager connection setup
If the private key is passphrase-protected, a window requesting the passphrase displays
before granting the connection (Figure 9-22).
Type the passphrase in the Password field. For a default key, use the passphrase provided
by ABB. For an updated key, use the passphrase defined for that key.
Click OK.
