7352 Series Digital Multimeter Operation Manual
6. HOW TO USE THE INTERFACE
6-1
6. HOW TO USE THE INTERFACE
The 7352A and 7352E include the following standard interfaces according to the model.
7352A USB, GPIB, and RS-232 interfaces
7352E USB interface
However, both interfaces cannot be used at the same time. Select either one.
6.1 Interface Selection
The interface can be selected and set only from MENU on the front panel.
1. Because the setting of the interface selection is saved in the nonvolatile memory, the setting does not
change even if the power is turned off or the interface is reset.
2. The address specific to the instrument is set in the interface. To identify each DMM on the USB inter-
face, the address of the USB interface (USB.ID) is set.
The address is displayed by turning on the power or using the address setting in MENU.
The interface setting item and the initial setting when shipping are shown below.
Setting item Initial setting when shipping
Header ON/OFF ON
GPIB address/USB.ID 1
GPIB talker function Addressable
Select the interface from GPIB and USB in ‘BUS’ in in .
Press to apply the setting.
Header ON/OFF
Select ON or OFF in ‘HEADER’ in in .
Press to apply the setting.
Table 6-1 Interface
Interface 7352A 7352E
GPIB -
USB
RS-232 -
To Next Page
