7352 Series Digital Multimeter Operation Manual
7.2 Interface Specifications
7-16
7.2 Interface Specifications
Item Specifications
Remote control
Remote command Compliance with the command format for ADC, SCPI and R6452A.
Interface
USB
Standard Full speed
Compliance with USB2.0
Connector Type B
GPIB (7352A)
Standard Compliance with IEEE488.2-1987
Connector 24-pin Anphenol
Interface functions SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT1, C0, E2
Output format ASCII
Addressing 31 kinds of talker/listener addresses can be specified from the front panel.
EIA232 (7352A)
Standard Compliance with EIA232 (RS-232)
Connector D-Sub9 pin
Baud rate 9600, 4800, 2400, 1200, 600, 300
Parity Even number (EVEN), odd number (ODD), or none
Number of data bits 7 bits or 8 bits
Number of stop bits 1 bit or 2 bits
Echo ON, OFF
External trigger signal (7352A)
Connector BNC
Signal level TTL Detecting the falling edge
Pulse width 1 s or more
