ADCMT 7352A - 5.9 Calculation Functions Overview

7352 Series Digital Multimeter Operation Manual
5.9 Calculation Functions
5-23
5.9 Calculation Functions
This instrument supports the following nine calculation functions.
Item Function
NULL calculation Subtracts a fixed value from a measurement value.
Smoothing calculation Calculates the moving average.
Scaling calculation
Calculates ( )  C.
dB calculation
Calculates 20 log
10
().
dBm calculation
Calculates 10 log
10
(  ).
Comparator calculation Performs a comparative calculation (HI/GO/LO).
MAX/MIN calculation Calculates the maximum, minimum and average values.
Statistical calculation Calculates the maximum value, minimum value, average value,
standard deviation, and dispersion for the data memory.
Calculation between 2 measure-
ments
Performs four arithmetic operations between measurements for
the left side (first) and the right side (second) displays.
M-B
A
M
D
M
2
D
1
10
-3
