7352 Series Digital Multimeter Operation Manual
4.1.1 Front Panel Description
4-3
8. Continuity(SHIFT + ACV) Selects the Ach continuity measurement.
9. Diode(SHIFT + ) Selects the Ach diode measurement.
10. DCI-Bch(SHIFT + DCI) Selects the Bch DC current measurement (DCI).
11. ACI/AC+DC-Bch(SHIFT + ACI) Selects the Bch AC current measurement (ACI).
AC coupling and AC+DC coupling are alternately switched by
pressing SHIFT and ACI while ACI-Bch is selected.
12. FREQ(SHIFT + TEMP) Selects the Ach AC voltage frequency measurement (FREQ).
4.1.1.4 Measurement Range Selection Keys
1. AUTO Switches the measurement range between auto-range and fixed
range.
2. DOWN Decreases the measurement range by one level and fixes the
range.
3. UP Increases the measurement range by one level and fixes the range.
4.1.1.5 Sampling Selection Keys
1. HOLD Holds or releases the sampling mode.
2. TRIG Starts the measurement when the sampling mode is set to HOLD.
3. RATE Sets the sampling rate to high (FAST), medium (MED), or low
speed (SLOW1 or SLOW2).
4.1.1.6 Calculation Selection Keys
1. NULL Sets or cancels the NULL calculation.
2. SM Sets or cancels the smoothing calculation.
4.1.1.7 MENU/ENTER Key
1. MENU Settings are configured by the MENU operation.
2. ENTER(For MENU operation) Saves the settings.
3. Selects a menu item and its layer.
