MENU
MEAS
A.ZERO Auto-zero
OFF/ON/ONCE
M.DISP Display mode
OFF/ON
DIGIT Number of display digits.
5 1/2 to 3 1/2
. BEEP The threshold in the continuity measurement function
1 to 1000
TEMP Temperature sensor selection
K TYPE/T TYPE
(a)
T.DELAY Trigger delay
0 s to 3600 s
*1
N.SMPL Sampling count
1 to 16000
SOURCE *2 Trigger source selection
IMMED/MANUAL/EXT(7352A)/BUS
T.COUNT Trigger count
1 to 50000
T.D.EACH Each trigger delay for the right and left displays
OFF/ON
COMP Comparative calculation
OFF/ON
MATH Other calculations
OFF/dB/dBm/SCL
MAX/MIN MAX/MIN calculation and selecting the display
OFF/ON/MAX/MIN
RESULT Display of the MAX/MIN calculation result
SAMPLE/MAX/MIN/AVG
PASS PASS condition settings (*2)
LOGOHI/____HI/__GO__/LO____/LO__HI/LOGO__/
__GOHI/______
BEEP Calculation Result and buzzer (*2)
OFF/PASS/FAIL
Calculation Result and buzzer (*2)
OFF/HI__LO/__GO__/HI____/____LO
SM.CNT Number of times smoothing is performed
2 to 100 times
2MEAS *2 Calculation for two measurement mode
OFF/(M1+M2)/(M1-M2)/(M1*M2)/(M1/M2)
*1 Trigger delay setting for each right and left display is available in T.D.EACH setting to
ON.
*2 It is available for only 7532A and 7352E.
Category layer Selection layer Entry/Execution layer
Each setting
for right and left
TRIG
CALC
To Next Page
