5. MENU OPERATION AND FUNCTION DESCRIPTION
5-1
5. MENU OPERATION AND FUNCTION DESCRIPTION
5.1 Menu
The functions and conditions in this instrument are set by using layered menus.
5.1.1 How to Navigate the Menus
Menus have a three-layer structure. (Some menus have a four-layer structure.)
First layer Category layer Selects the menu category.
Second layer Selection layer Selects the setting parameters in the category.
Third layer Entry/Execution layer Used to enter the values or select the setting.
Figure 5-1 Menu Operation
1. Press .
The Category layer in which to be selected is displayed.
2. Select the category by using and .
Measured value display
Note
Italic:Entry item
Under line
: Cursor blinks
Category layer
Selecting the category
Selection layer
Selecting the parameter
Entry/Execution layer
When selecting a setting and executing the selection
1
When entering the numerical value
2
Determine the entered value and move to the upper layer.
Category
Category
Parameter
Parameter
Parameter
Select the digit, decimal point, and unit by using and change the setting by using .
Cancel those
settings and
return to the
measured
value
MENU
MEAS
SYSTEM
