7352 Series Digital Multimeter Operation Manual
7.1.5 AC Current Measurement (ACI, ACI(AC+DC))
7-8
7.1.5 AC Current Measurement (ACI, ACI(AC+DC))
7.1.5.1 Ach AC Current Measurement (ACI-Ach and ACI(AC+DC)-Ach)
Measurement method True RMS measurement, RMS display
Input range 5% or more of a full scale
Crest factor 3:1 at a full scale
Temperature coefficient (1/10 of measurement accuracy that includes the additional error)/C in each
range and frequency range
Response time Approx. 1 s (Time until the measurement value reaches within 0.1% of the
final value in the same range)
ACI-Ach
ACI(AC+DC)-Ach
Input
terminal
Range
Maximum display Resolution
Resistance between terminals
(A fuse resistance is included.)
FAST/MED SLOW1, 2 FAST/MED SLOW1, 2
mA-COM A 200 A 199.99 199.999 10 nA 1 nA 102 or less
2000 A 1999.9 1999.99 100 nA 10 nA
20 mA 19.999 19.9999 1 A 100 nA 2 or less
200 mA 199.99 199.999 10 A1 A
2000 mA 1999.9 1999.99 100 A 10 A0.6 or less
Range
Measurement accuracy *1 (% of reading + digits)
20 Hz - 45 Hz 45 Hz - 1 kHz 1 kHz - 5 kHz
200 A 0.4+200 0.3+200 0.3+100
2000 A 0.5+200 0.35+100 0.35+200
20 mA 0.4+200 0.3+200 0.3+100
200 mA 0.4+200 0.3+200 0.3+100
2000 mA 0.5+200 0.35+100 0.7+200
*1: For sine-wave input When RATE is set to FAST or MED, the digit term is reduced
to 1/10 of its specification.
Input
terminal
Range
Maximum display Resolution
Resistance between terminals
(A fuse resistance is included.)
FAST/MED SLOW1, 2 FAST/MED SLOW1, 2
mA-COM A 200 A 199.9 199.99 100 nA 10 nA 102 or less
2000 A 1999 1999.9 1 A 100 nA
20 mA 19.99 19.999 10 A1 A2 or less
200 mA 199.9 199.99 100 A 10 A
2000 mA 1999 1999.9 1 mA 100 A0.6 or less
To Next Page
