7352 Series Digital Multimeter Operation Manual
7.1.4 DC Current Measurement (DCI)
7-7
7.1.4.2 Bch DC Current Measurement (DCI-Bch)
Input
terminal
Range
Maximum display Resolution
Resistance
between
terminals
(A fuse
resistance is
included.)
Measurement accuracy *1
(% of reading + digits)
Temperature
coefficient
(ppm of reading
+ digits)/C
FAST
MED/
SLOW1, 2
FAST
MED/
SLOW1, 2
FAST MED SLOW1, 2
Auto-
zero
ON
Auto-
zero
OFF
A-
COM B
10 A 11.999 11.9999 1 mA 100 A0.03 or less 0.2+2 0.2+7 0.2+5 200+0.6 200+3
*1: For Auto-zero ON For Auto-zero OFF, 2 digits are added to the digit term.
Maximum allowable
applied current
Input protection Fuse replacement
Between A and
COM B terminals
10 A Protected by the15 A/250 V fast-blow
fuse with 10000 A breaking capacity.
Contact ADC CORPORA-
TION to repair.
