7352 Series Digital Multimeter Operation Manual
5.9.5 Comparator Calculation
5-34
The PASS conditions are set in .
1. Press in the current set value display state (PASS) to enable the PASS setting
mode.
2. Select the PASS condition by using and .
6. Canceling the comparator calculation
The comparator calculation is canceled when any of the following conditions occur.
• The comparator calculation is set to OFF while the comparator calculation is performed.
• The measurement function is changed.
• The *RST command is executed.
7. Changing the measurement range and comparator operation
The comparator function operates continuously even if the measurement range is changed.
The reference values for the judgment are not changed because the values and the unit are set.
Table 5-6 PASS Condition Setting and PASS/FAIL Judgment
Judgment result
Hi PASS PASS FA I L FAIL PA S S FA I L PASS FA I L
Go PASS FA IL PASS FA IL FAIL PASS PAS S FAIL
Lo PASS FAIL FAIL PA S S PASS PA S S FAIL FAIL
PASS condition
setting
Panel setting LGH – – H – G – L – – L – H LG – – GH – – –
Remote
command
LOP1 LOP0 LOP0 LOP1 LOP1 LOP1 LOP0 LOP0
MIP1 MIP0 MIP1 MIP0 MIP0 MIP1 MIP1 MIP0
HIP1 HIP1 HIP0 HIP0 HIP1 HIP0 HIP1 HIP0
MENU CALC PASS LOGOHI/_ _ _ _HI/_ _GO_ _/LO_ _ _ _/
LO_ _HI/LOGO_ _/_ _GOHI/_ _ _ _ _ _
To Next Page
