7352 Series Digital Multimeter Operation Manual
6.6.2 Output Data Format
6-15
5. Output data element
Description Sub header Priority
Error information Out of range O 1
Calculation Scaling error and OL for the calculation between 2
measurements
O1
Err D (dB/dBm calculation error and zero division
for the calculation between 2 measurements)
E2
Calculation result
information
Comparator
result
HIGH H 3
GO P 3
LOW L 3
Calculation between 2 measurements (Only 2nd display side) D 3
MAX data M 4
MIN data I 4
AV E d a t a A 4
dB data B 5
dBm data W 5
Scaling calculation data S 6
NULL calculation data N 7
Other than those above _ 8
Calculation between
2 measurements
Measurement for 1st display + Measurement for 2nd display ADD
Measurement for 1st display - Measurement for 2nd display SUB
Measurement for 1st display * Measurement for 2nd display MUL
Measurement for 1st display / Measurement for 2nd display DIV
OFF OFF
