Chapter 2: Setup
19
OsmoTECH PRO Multi-Sample Micro-Osmometer Service Guide
• Press the LAN/LIS tab for information on the
following icons that indicate the status of an
instrument connected to a local area network (LAN)
or a Laboratory Information System (LIS).
Item Description
LIS
Gray: Disabled
Red: Enabled and disconnected
Green: Enabled and connected
LAN
Green: Connected
Gray: Disconnected
• Press the Access levels tab for information on the
following icons that indicate the access levels of
instrument users.
Item Description
Access levels
Red: Administrator
Yellow: Supervisors, administrators
White: Operators, administrators
Yellow, white: All users
• Press the Indicators tab for information on the
following icons that indicate pending tasks requiring
user action.
Item Description
Indicators
Appears when the Result PDF Export
Enabled checkbox is selected.
Shows the number of result PDF files
currently stored on the instrument and
waiting to be sent to the network (see
Exporting results in the OsmoTECH PRO
User’s Guide (p/n 222005UG).
Appears when the Review of Results and/or
Approval of Results checkbox is selected.
Shows the combined number of result
records currently awaiting review or approval
(see Signing for reviews and approvals in the
and Configuring audits of test results).
Appears when an error occurs. Press this
icon to view error information (see
Calibration and Troubleshooting).
Viewing instrument assistance information
On the Home screen, press to open the ASSISTANCE
INFORMATION screen.
• Press the Advanced Instruments tab to view
Advanced Instruments contact information.
