Chapter 5: Configuring settings
35
OsmoTECH PRO Multi-Sample Micro-Osmometer Service Guide
5.3 Changing the probe resistance
Do not change the probe resistance setting unless you
are replacing the sample probe or block probe.
NOTE: Access to SETTINGS> PROBE RESISTANCE
depends on the Enter Probe Resistance checkbox
setting on the SUPERVISOR ACCESS and
OPERATOR ACCESS tabs (see Assigning user
restrictions).
NOTE: If you change the sample or block probe
resistance, you must recalibrate the instrument.
1. Press PROBE RESISTANCE.
2. Log into your account.
3. Press next to the field you want to change.
4. Make your changes and press SAVE.
5.4 Setting up networking communications
Your network administrator can help you set up your
instrument to connect to a network in order to send
data, back up files, or use a network time server.
NOTE: Access to SETTINGS > NETWORKING depends on
the Change Network checkbox setting on the
SUPERVISOR ACCESS and OPERATOR ACCESS
tabs (see Assigning user restrictions).
Configuring a LAN connection
The instrument can connect to a computer or other
devices over a local area network (LAN).
1. Plug an Ethernet cable into the Ethernet connector.
2. Press NETWORKING and log in.
3. Press the LAN tab.
4. Select one of the following network protocols:
• Static IP (recommended for best results):
Assigning an unchanging static IP address to the
instrument makes it easier for other devices to
contact the instrument over the network.
a. Press and enter the IP Address.
b. Press and enter the Subnet Mask.
c. Press and enter the Default Gateway.
• DHCP (Dynamic Host Configuration Protocol): A
DHCP server dynamically assigns an IP address and
other network parameters to the instrument.
The IP Address, Subnet Mask, and Default Gateway
are entered automatically, and can change each
time the instrument connects to the network.
5. Enter the host name (up to 32 characters)—especially if
other OsmoTECH PROs are connected to the network.
6. Press Save.
