Technical data of the device
DLT-V83 Operating Instructions V2.00 25 / 157
Power supply, power consumption, power supply unit fuses
Power supply, power consumption
AC power supply unit, internal, Type: AC-4 Electrically isolated
Rated voltage 100 to 240 VAC
Voltage range 85 to 264 VAC
Input frequency 50/60 Hz
Bridgeable power failures Typically 22 ms at Uin = 115 VAC
Maximum output power 60 W
Rated current 1 A max.
Power consumption:
DLT-V8315 with
Intel
®
Atom™ D525 CPU
Typically 30 W
Power consumption:
DLT-V8315 with Intel
®
Core™ i5-4300U
CPU and Intel
®
Celeron
®
2980U CPU
Typically 40 W
Power supply unit fuses
Power supply unit Fuse type Example
AC- 4 5 x 20 mm
T 1.0 A H / 250
V
Bussman S505-1-R
Littelfuse 0215 001.
Schurter 0001.2504
Siba 179200.1
or similar produced by other manufacturers
The symbol for the fuse is FA.
You will find the exact position on the sticker located on the connection plate of the DLT-V83.
