Technical data of the device
26 / 157 DLT-V83 Operating Instructions V2.00
Measurement results of the power consumption according to ErP
Test results
Idle Mode 24.22 W
Sleep Mode 0.91 W
Soft-Off-Mode (S5) 0.91 W
Lowest Power State 0.00 W (with special connection cable)
Total Energy Consumption (ETEC) 90.07
To facilitate achieving the lower power state:
Set the switch of the Advantech power supply cable to Off.
Test conditions
Required Actual
Input voltage 230 (±1 %) V a.c. 229.82 – 230.05 V
THD < 2 % < 2 %
Frequency 50 Hz (±1 %) 5 0 Hz
Ambient temperature (23 ±5) °C 23.3ºC
Ambient humidity 10 to 80 % 31 %RH
Ambient light (250 ±50) Lux / (no automatic display luminance
control
Power analyzer used N4L type PPA1530
(SIQ ID 503; Calibration valid till 2015-07-01)
