2.
Generator settings for DSA image acquisition (DSA is not part of this
workflow)
3.
Generator settings for fluoroscopy or for roadmapping image
acquistion
4.
Automatic position
Figure 114: Examination overview
a) Check the X-ray modality settings.
Figure 115: X-ray modality controls on the software console
b) Check the exposure settings.
The DSA acquisition group contains settings for fluoroscopy, for static
images, for DSA exposures (based on rapid sequence) and for
roadmapping (based on fluoroscopy).
Figure 116: Generator controls for static images and for DSA
Figure 117: Generator controls for fluoroscopy and for roadmapping
3. Move the X-ray system to the right position.
a) Check if a correct automatic position is selected.
Figure 118: Positioning controls on the software console
b) Move the X-ray system to the selected automatic position.
The actual and target position parameters are displayed on the
software console. When the target position is reached, the movement
stops.
c) Adjust the position using the position controls.
4. Position the patient.
Use patient fixations available to avoid patient movement during
interventional procedures.
The patient position can be verified using the collimator camera.
5. On the collimator, switch on the light localizer. Apply collimation.
6. Acquire a set of roadmapping examinations, DSA sequences, fluo
sequences and static images.
