Menu Example 3 Some commands in the menu require that you enter a numeric
parameter value. The following steps show you how to enter a number in
the menu. For this example, you will set the null value for channel 1 to
–30 millivolts.
Make sure the meter has channel 1 selected, is in the dc voltage function,
and has 6
1
⁄
2
digits displayed. Connect the four-wire short to the meter
input.
On/Off
Shift < 1 Turn on the menu.
You enter the menu on the menus level. The MEAS MENU is your first
choice on this level.
A: MEAS MENU
> > 2 Move across to the MATH MENU choice on this level.
There are six menu group choices available on this level.
C: MATH MENU
v 3 Move down to the commands level within the MATH MENU.
The STATS command is your first choice on this level.
1: STATS
> 4 Move across to the NULL VALUE command.
2: NULL VALUE
Chapter 2 Front-Panel Operation
A Front-Panel Menu Tutorial
38
