CALCulate[1|2|3|4]:MARKer:DTABle:COPY[1|2|3|4] command
Copies the data table from one trace to another trace.
Command Syntax: CALCulate[1|2|3|4]:MARKer:DTABle:COPY[1|2|3|4]
Example Statements: OUTPUT 711;":calc4:marker:dtab:copy1"
OUTPUT 711;"CALC:MARK:DTABLE:COPY3"
Attribute Summary: Option: not applicable
Synchronization Required: no
Preset State: not applicable
SCPI Compliance: instrument-specific
Description:
Use the trace specifier, COPY[1|2|3|4], to indicate the source, which trace the data table is to be copied
from. Use the trace specifier, CALCulate [1|2|3|4], to indicate the destination, which trace the data table
is to be copied to.
1 specifies the data table appearing in trace box A, 2 specifies B, 3 specifies C, and 4 specifies trace box
D. If a trace specifier is not used, the trace defaults to trace A.
Note The analzyer does not verify the traces are compatible.
CALCulate
6-58
