GPIB Interface Capabilities
The Agilent 35670A has the following interface capabilities, as defined by the IEEE 488.1 standard:
SH1 full Source handshake capability
AH1 full Acceptor handshake capability
T6 basic Talker, Serial Poll, no Talk Only, unaddress if MLA
TE0 no Extended Talker capability
L4 basic Listener, no Listen Only, unaddress if MTA
LE0 no Extended Listener capability
SR1 full Service Request capability
RL1 full Remote/Local capability
PP0* Parallel Poll capability
DC1 full Device Clear capability
DT1 full Device Trigger capability
C1 System Controller capability
C2 send IFC and take charge Controller capability
C3 send REN Controller capability
C4* respond to SRQ
C6* send IFC, receive control, pass control, parallel poll, pass control to self
C10* send IFC, receive control, pass control, parallel poll
C12 send IF messages, receive control, pass control
E2 tri-state drivers
* only when an Instrument BASIC program is running
