*TRG command
Triggers the analyzer when TRIG:SOUR is BUS.
Command Syntax: *TRG
Example Statements: OUTPUT 711;"*trg"
OUTPUT 711;"*Trg"
Attribute Summary: Option: not applicable
Synchronization Required: no
Preset State: not applicable
SCPI Compliance: confirmed
Description:
This command triggers the analyzer when the following two conditions are met:
The GPIB is designated as the trigger source. (See the TRIG:SOUR BUS command.)
The analyzer is waiting to trigger. (Bit 5 of the Operation Status register must be set). It is ignored at
all other times.
The *TRG command has the same effect as TRIG:IMM. It also has the same effect as the GPIB bus
management command Group Execute Trigger (GET).
Common Commands
3-18
