Agilent Technologies E4406A VSA Series Service Guide

Chapter 2 109
Block Diagrams
Mnemonics and Connectors
Table 2-15 A21J17 CPU - Power Supply Connector
Pin Signal Pin Signal
1 N12 51 N12
2 N12 52 N12
3 P12 53 P12
4 P12 54 P12
5 DCOM 55 VCC
6DCOM56 VDL
7DCOM57 VDL
8DCOM58 VDL
9 DCOM 59 VCC
10 DCOM 60 VDL
11 DCOM 61 VDL
12 DCOM 62 VDL
13 DCOM 63 VCC
14 DCOM 64 VDL
15 DCOM 65 VDL
16 DCOM 66 VDL
17 DCOM 67 VCC
18 DCOM 68 VDL
19 DCOM 69 VDL
20 DCOM 70 VDL
21 DCOM 71 VCC
22 DCOM 72 VDL
23 DCOM 73 VDL
24 DCOM 74 VDL
25 DCOM 75 VCC
26 DCOM 76 VDL
27 DCOM 77 VDL
28 DCOM 78 VDL
29 DCOM 79 VCC
30 DCOM 80 VDL
31 DCOM 81 VDL
32 DCOM 82 VDL
33 DCOM 83 VCC
34 DCOM 84 VDL
35 DCOM 85 VDL
36 DCOM 86 VDL
37 DCOM 87 VCC
38 DCOM 88 VDL
39 DCOM 89 VDL
40 DCOM 90 VDL
41 DCOM 91 VCC
42 DCOM 92 VDL
43 DCOM 93 VDL
44 DCOM 94 VDL
45 DCOM 95 VCC
46 DCOM 96 VDL
47 DCOM 97 VDL
48 DCOM 98 VDL
49 ACOM 99 ACOM
50 ACOM 100 ACOM
