Agilent Technologies E4406A VSA Series Service Guide

112 Chapter 2
Block Diagrams
Mnemonics and Connectors
Reference Assembly Connectors
Table 2-19 A15J31
Pin Signal Pin Signal
1 ACOM 11 ACOM
2 10MHZ_EXT_OUT 12 ACOM
3 ACOM 13 10MHZ_EXT_IN
4 ACOM 14 ACOM
5 ACOM 15 10MHZ_CPU
6 10MHZ_RF 16 ACOM
7ACOM1710MHZ_OPT
8 10MHZ_SYNTH 18 ACOM
9 ACOM 19 10MHZ_AIF
10 ACOM 20 ACOM
Table 2-20 A15J32
Pin Signal Pin Signal
1 ACOM 16 ACOM
2 N15 17 N15
3N618N6
4 N5.219N5.2
5 P920P9
6P1521P15
7 P32 22 P15SBY
8 ACOM 23 ACOM
9 ACOM 24 REF_CK
10 ACOM 25 REF_EN
11 REF_DATA 26 ACOM
12 ACOM 27 ACOM
13 ACOM 28 ACOM
14 P5.2 29 P5.2
15 ACOM 30 ACOM
