Agilent Technologies E4406A VSA Series Service Guide

110 Chapter 2
Block Diagrams
Mnemonics and Connectors
Daughterboard Connectors
RF Assembly Connectors
Table 2-16 A15J21
Pin Signal Pin Signal
1 ACOM 11 ACOM
2 PRE_LEVEL_DRIVE 12 ACOM
3 ACOM 13 ACOM
4 ACOM 14 ACOM
5 ACOM 15 ACOM
6ACOM1610MHZ_RF
7 ACOM 17 ACOM
8 ACOM 18 CALOSC_H
9 ACOM 19 CALOSC_L
10 ACOM 20 ACOM
Table 2-17 A15J22
Pin Signal Pin Signal
1 ACOM 16 ACOM
2 N15 17 N15
3N618N6
4 N5.219N5.2
5 P920P9
6P1521P15
7P3222ACOM
8 ACOM 23 ACOM
9ACOM24RF_CK
10 ACOM 25 RF_EN
11 RF_DATA 26 ACOM
12 ACOM 27 ACOM
13 ACOM 28 ACOM
14 P5.2 29 P5.2
15 ACOM 30 ACOM
