114 Chapter 2
Block Diagrams
Mnemonics and Connectors
Synthesizer Assembly Connectors
Table 2-22 A15J41
Pin Signal Pin Signal
1 ACOM 11 ACOM
2 ACOM 12 ACOM
3 ACOM 13 ACOM
4 ACOM 14 ACOM
5 ACOM 15 ACOM
6 ACOM 16 ACOM
7 ACOM 17 ACOM
8 ACOM 18 ACOM
9 ACOM 19 ACOM
10 MIDGEN_CLEAN 20 ACOM
Table 2-23 A15J42
Pin Signal Pin Signal
1 ACOM 16 ACOM
2 N15 17 N15
3N618N6
4 N5.219N5.2
5 P920P9
6P1521P15
7P3222ACOM
8 ACOM 23 ACOM
9ABUS24SYNTH_CK
10 ACOM 25 SYNTH_EN
11 SYNTH_DATA 26 ACOM
12 ACOM 27 ACOM
13 ACOM 28 ACOM
14 P5.2 29 P5.2
15 ACOM 30 ACOM
