Agilent Technologies E4406A VSA Series Service Guide

Chapter 2 99
Block Diagrams
Mnemonics and Connectors
Motherboard Connectors
Table 2-4 A21J1/J3/J4 Fan Connectors
Pin Signal
1NC
2VFAN −
3VFAN +
Table 2-5 A21J2 Fan Control Connector
Pin Signal Pin Signal
1VFAN − 21 VFAN +
2VFAN − 22 VFAN +
3VFAN − 23 VFAN +
4ACOM24 P15
5ACOM25 P15
6ACOM26 P15
7ACOM27 NC
8 ACOM 28 DAUGHTER_OTP
9ACOM29SW_IN_L
10 ACOM 30 PS_OFF_L
11 ACOM 31 POWFAILL
12 ACOM 32 REMOTE_ON_L
13 PROBE_P15 33 ACOM
14 ACOM 34 P15
15 PROBE_N12.6 35 ACOM
16 ACOM 36 N15
17 FP_P5.2 37 ACOM
18 ACOM 38 P5.2
19 FP_P15SBY 39 ACOM
20 N6 40 P15SBY
