Agilent Technologies E4406A VSA Series Service Guide

100 Chapter 2
Block Diagrams
Mnemonics and Connectors
Table 2-6 A21J5 Power Supply Connector
Pin Signal Pin Signal
1 P32 41 P32
2 ACOM 42 ACOM
3 P15 43 P15
4 P15 44 P15
5 ACOM 45 ACOM
6 P946P9
7 P947P9
8 ACOM 48 ACOM
9 N5.249N5.2
10 N5.2 50 N5.2
11 ACOM 51 ACOM
12N1552N15
13N1553N15
14 ACOM 54 ACOM
15 P5.2 55 P5.2
16 P5.2 56 P5.2
17 ACOM 57 ACOM
18 P5.2 58 P5.2
19 P5.2 59 P5.2
20 ACOM 60 ACOM
21 VCC 61 VCC
22 VCC 62 VCC
23 DCOM 63 DCOM
24 DCOM 64 DCOM
25 VCC 65 VCC
26 DCOM 66 DCOM
27 DCOM 67 DCOM
28 VDL 68 VDL
29 VDL 69 VDL
30 DCOM 70 DCOM
31 DCOM 71 DCOM
32 VDL 72 VDL
33 DCOM 73 DCOM
34 DCOM 74 DCOM
35 VDL 75 VDL
36 VDL 76 VDL
37 DCOM 77 DCOM
38 ACOM 78 ACOM
39 PS_FREQ 79 PS_OFF_L
40 LINE_TRIG 80 P15SBY
