Agilent Technologies E4406A VSA Series Service Guide

Chapter 2 101
Block Diagrams
Mnemonics and Connectors
Table 2-7 A21J6 Daughter Board Connector
Pin Signal Pin Signal
1 ACOM 51 ACOM
2 P15SBY 52 P15SBY
3 P15SBY 53 P15SBY
4 ACOM 54 ACOM
5 P32 55 P32
6 P32 56 P32
7 ACOM 57 ACOM
8 P15 58 P15
9 P15 59 P15
10P1560P15
11 ACOM 61 ACOM
12 P9 62 P9
13 P9 63 P9
14 P9 64 P9
15 ACOM 65 ACOM
16 N5.2 66 N5.2
17 N5.2 67 N5.2
18 N5.2 68 N5.2
19 ACOM 69 ACOM
20 N6 70 N15
21N1571N15
22N1572N15
23 ACOM 73 ACOM
24 P5.2 74 P5.2
25 P5.2 75 P5.2
26 P5.2 76 P5.2
27 ACOM 77 ACOM
28 LADDR 78 ACOM
29 SCLK 79 ACOM
30 LDATA 80 ACOM
31 MOSI 81 ACOM
32 LCNTRL 82 ACOM
33 MISO 83 ACOM
34 LSRQ 84 ACOM
35 HPUP 85 ACOM
36 TRIG1 86 ACOM
37 TRIG2 87 ACOM
38 DPT_TRIG1 88 ACOM
39 DPT_TRIG2 89 ACOM
40 DAUGHTER_OTP 90 ACOM
41 LO_LOCK 91 ACOM
42 ACOM 92 ACOM
43 CALOSC_L 93 ACOM
44 CALOSC_H 94 ACOM
45 ACOM 95 ACOM
46 10MHZ_AIF 96 ACOM
47 ACOM 97 ACOM
48 10MHZ_OPT 98 ACOM
49 ACOM 99 ACOM
50 10MHZ_CPU 100 ACOM
