Block Diagrams
Mnemonics and Connectors
Table 2-8 A21J7 Floppy FFC Cable Connector
Pin Signal Pin Signal
1 FLOPPY_HSL 14 NC
2 DCOM 15 FLOPPY_DIRCL
3 FLOPPY_RDDL 16 NC
4 DCOM 17 FLOPPY_DS3L
5 FLOPPY_WPL 18 FLOPPY_MID
6 DCOM 19 FLOPPY_READY
7 FLOPPY_TR00L 20 NC
8 DCOM 21 FLOPPY_DCHGL
9 FLOPPY_WEL 22 VCC
10 DCOM 23 FLOPPY_DS1L
11 FLOPPY_WDL 24 VCC
12 DCOM 25 FLOPPY_IDXL
13 FLOPPY_STEPL 26 VCC
