Agilent Technologies E4406A VSA Series - Page 118

118 Chapter 2
Block Diagrams
Mnemonics and Connectors
Table 2-29 A15J52
Pin Signal Pin Signal
1 ACOM 16 ACOM
2 N15 17 N15
3N618N6
4 N5.219N5.2
5 P920P9
6P1521P15
7P3222ACOM
8 ACOM 23 ACOM
9ACOM24 NC
10 ACOM 25 NC
11 NC 26 ACOM
12 ACOM 27 ACOM
13 ACOM 28 ACOM
14 P5.2 29 P5.2
15 ACOM 30 ACOM
Table 2-30 A15J53
Pin Signal Pin Signal
1 ACOM 11 ACOM
2 ACOM 12 ACOM
3ACOM13 NC
4 ACOM 14 ACOM
5ACOM15 NC
6 ACOM 16 ACOM
7ACOM17 NC
8 ACOM 18 ACOM
9ACOM19 NC
10 ACOM 20 ACOM
