Agilent Technologies E4406A VSA Series Service Guide

140 Chapter 3
Parts List
Replaceable Parts
Table 3-7 Connectors
Reference
Designator
Description Agilent Part Number
J5 Ext Trigger
Part of W3 cable
J7 Probe Power
Part of A3 Front Panel Interface Assembly
1252-7437
J10 RF In 1250-1811
A27 J2 Ext Ref IN
Part of A27 Rear Panel Connector Board
A27 J3 10 MHz Out
Part of A27 Rear Panel Connector Board
A27 J4 Trig 1 Out
Part of A27 Rear Panel Connector Board
A27 J5 Trig 2 Out
Part of A27 Rear Panel Connector Board
J22 SCSI
Part of the A25 PS2 Board Plus SCSI
J23 KEYBD
Part of the A25 Digital I/O Board
P7 Serial
Part of A22 CPU (Processor) Assembly
1252-6672
J13 Monitor
Part of A22 CPU (Processor) Assembly
1252-6671
J14 Parallel
Part of A22 CPU (Processor) Assembly
1252-5706
J12 LAN-TP
Part of A22 CPU (Processor) Assembly
1252-5586
J15 GPIB
Part of A22 CPU (Processor) Assembly
1252-2161
J18 Ext Trig Input
Part of W20
