Chapter 1 21
Troubleshooting
Service Equipment You Will Need
Type-N (f) to BNC (m) 50Ω 1250-1477 P, T
Type-N (m) to BNC (m) 50Ω 1250-1473 P, T
Type-N (m) to BNC (f) 50Ω 1250-1476 A, P, T
APC-3.5 mm (f)
to Type-N (f)
For 83620B 1250-1745 A, P
7 mm to Type-N (f) (included in calibration kit) P
Filters
50 MHz Low Pass Cutoff Frequency: 50 MHz
Rejection at 65 MHz: >40 dB
Rejection at 75 MHz: >60 dB
0955-0306 P, T
Controller
Computer IBM compatible PC
Intel Pentium 200 MHz + higher
Windows 2000
®
or NT
®
4.0 or XP
®
32 MB RAM
At least 200 MB of free hard disk space
CD-ROM Drive
800x600 Minimum monitor resolution
Web browser
b
P, A
Accessories
IEEE 488 Interface Card
High-performance GP-IB or GPIB
c
(Must support VTL)
82341D, 82350B,
82357A
National p/n
AT-GPIB/TNT
P, A
Software Performance verification and adjustment
software for E4406 VSA
N7812A P, A
Service Kit Includes three extender boards required for
troubleshooting
E4406-60114 T
Hand Tools
Torx Driver T-10 8710-1623
Torx Driver T-15 8710-1622
Torx Driver T-20 8710-1615
Nut Driver 9/16 inch deep socket for BNC removal 8720-0008
Diagonal Cutters no specification 8710-1294
a. A = Adjustments, P = Performance Testing, T = Troubleshooting.
Use the N7812A software to perform the tests and adjustments.
b. Microsoft
®
Internet Explorer
®
4.0 or greater or Netscape
®
4.0 or greater.
Table 1-2 Required Test Equipment Summary (Continued)
Instrument Critical Specifications Recommended
Agilent Model
Number
Alternative
Agilent Model
Number
Use
a
